Tru-Test HD5T Load Bars

$2,595.00

HD5T 11,000 lb Capacity TRU-TEST Load Bars

Tough, reliable and easy to Install under your squeeze chute.

Tru-Test load bars are recognized for their rugged durability and performance in harsh environments. The HD5T Load Bars are designed to be tough, reliable and easy to install under any manual or hydraulic squeeze chute. The simplicity of set up means you can easily install with no assistance needed.

With a capacity suitable for the heaviest of cattle squeeze chutes, you will have outstanding performance with the best weighing set up for your animals.



KEY FEATURES

Extremely easy to install. Simply bolt it to the squeeze chute and then bolt to the level concrete surface.

More capacity. The 11,000 lb capacity and 1010 mm long heavy duty load bar is suitable to mount under the heaviest of cattle squeeze chutes.

Sealed load cell. Protects the load cell against moisture damage allowing the load bars to remain outside under the chute.

Corrosion resistant. Galvanized steel construction means the HD5T Load Bars can endure the harshest agricultural environment.

Robust. Heavy duty TPR/PVC cables are a standard feature, which minimize the likelihood of cable damage.



TECHNICAL SPECIFICATION

CABLE LENGTH

16 ft (5 m)

OVERALL HEIGHT

4.3″ (110 mm)

BAR SECTION WIDTH

3″ (75 mm)

RESOLUTION

Base resolution with Tru-Test scales: 2 x HD5T load bars = 1.10 lb (0.5 kg).

TOTAL CAPACITY

2 x HD5T load bars = 11,000 lbs (5,000 kg).

NOMINAL LENGTH

43" (1115 mm).

ACCURACY

+/- 1 % or 2 resolutions, whichever is greater.

WEIGHT

Pair: 80 lbs (36 kg)
