Macnaught 5:1 Air Operated Oil Pump - PN# T512-02


The Macnaught T Series range of Oil Pumps are high quality, economically priced oil pumps. The ideal choice for small workshop or service truck applications. The ‘T’ Series range of pumps have been designed with a non-corrosive air motor that does not require any oil lubrication, the pump has very low air consumption and the noise levels during operation are very low. The “T” series design includes a built in pressure relief valve to protect against pressure build up caused by thermal expansion suitable for oils and premix coolants up to SAE140 viscosity.

Needs the TB23S drop tube as well.


Macnaught Air Operated Oil Pump Specifications

Model number T512-02
Pump ratio 5:1 ratio
Output SAE 10 3.5 GPM
Output SAE 15W-40 3 GPM
Output SAE 90 2.9 GPM
Maximum Static Head 160ft (50m)
Pressure relief valve
2" Bung adapter
Fully serviceable
Warranty¹ 10 years
Parts guarantee² 10 years
Compatible fluids Engine and gear oils up to SAE90, auto trans, hydraulic fluid and anti-freeze / anti-boil
Min-Max air pressure 60/150psi (400-1030kPa)
Min air compressor 5cfm/min (0.15m³)
Air inlet 1/4" NPT(F)
Pump outlet 1/2" NPT(F)
Pump inlet 1"  NPT (F)
